Quick Details

  • Standard: AISI, ASTM, BS, DIN, GB, JIS
  • Grade: CCO
  • Thickness: overlayer 3~20mm, base plate 3 ~40mm
  • Place of Origin: Tianjin, China (Mainland)
  • Brand Name: WODON
  • Model Number: WD10on10
  • Type: Steel Plate
  • Technique: open arc and submerged arc welding
  • Surface Treatment: Coated
  • Application: wear resistance in mining, cement, steel, coal, port, etc.
  • Special Use: Wear Resistant Steel
  • Width: 1400~2200 mm
  • Length: 3000~3500 mm
  • product name: China factory Hardfaced wear plate for vibrating feeders
  • hardness: 58~65 HRC
  • Cr content: 15~40%
  • Certificate: ISO9001:2008
  • common sizes in stock: 4on4, 4on6, 4on8, 5on5, 6on6, 6on8, 6on10, 6on12, 8on8, 8on10, 10on10
  • surface: high carbon high chrome
  • impact resistance: low and moderate
  • Cr7C3: 50 %
  • tempreture: 0~600 ℃
  • weld beads pattern: straight, wave, zick zack

Packaging & Delivery

Packaging Details on steel pallet, package size are 1400*3500mm and 2100*3500mm, load into 20ft container.
Delivery Time 7~45 days
product description

China factory Hardfaced wear plate for vibrating feeders

 ISO9001 certified bimetal abrasion resistant steel plate



Product Name
Chromium carbide overlay wear plate hardfacing meterial
Material
Q235/Q345+Chromium carbide overlay
Base metal
Q235/Q345
Hardfacing layer
Chromium carbide overlay
Chemical composition
C: 3.0-5.0% Cr:25-40%
Hardness
HRC58-65
Microstructure
Carbide (Cr7C3)volume fraction above 50%
Wear resistance
High wear/abrasion resistance
Flatness tolerance
±3mm/m
Thickness tolerance
uniform overlay thickness, with tolerance within 0-0.5mm
Impact resistance
Medium
Technology
Hardfacing, open arc welding, submerged arc welding

Plate Size
Open arc welding wear  plate: 1400*3400mm
Submerged arc welding wear plate : 1400*3000mm, 1400*3500mm, 2100*3500mm


Main thicknesses
3+3,4+4,5+5,6+4,6+5,6+6,8+4,8+5,8+6,8+7,8+8,10+4,10+5,10+6,10+7,10+8,10+9,10+10,10+20,12+4,12+5,12+6,12+7,12+8,12+9,12+1,12+11,12+12,14+6,14+8,14+10,16+6,16+8,16+10,18+6,18+8,18+10,20+5,20+6,20+8,20+10,20+20,30+10,40+10, customized thicknesses.
Company Information

Since 2004, Wodon has more than 200 employees.

 Wodon product: flux cored welding wires, chromium carbide overlay steel plates, wear resistant partss, wear pipes, wear fittings.

Welding wire and wear plate workshops



Wodon's quality managment

Warehouse





Packaging & Shipping

Packaging Details: steel pallets and film wrapped







Advantages

Why our wear plate has such good wear resistance?

1. The overlay chemical composition is the key

The main ingredients of Wodon plates are C(%) :3.0-5.0 and Cr(%):25-40. This chemical proportion results in a large amount of Cr7C3 chrome carbide hard particles. The micro-hardness (up to HV1800) of these particles throughout the layer will guarantee a super wear resistant surface.

Performance test:

Test equipment: Quartz sand rubber wheel abrasion test machine.

Conditions: Choosing same dimension specimens for different materials and wear plate producers, and put them under the same wearing working conditions in our testing equipment.

          45 minutes for each specimen.

No.

Wear Plate Type

Test Time

Weight Loss of Overlay

1

Wodon Wear Plate

45 minutes

0.148g

2

Imported Wear Plate

45 minutes

0.229g

3

Imported Wear Plate

45 minutes

0.237g

4

Imported Wear Plate

45 minutes

0.252g

5

Domestic Wear Plate

45 minutes

0.385g

6

Domestic Wear Plate

45 minutes

0.377g

7

Domestic Wear Plate

45 minutes

0.399g

8

Domestic Wear Plate

45 minutes

0.371g

Results: The test results show that the life span of Wodon wear plate is 2.5 times higher than domestic wear plates and 1.5 times than imported ones.

2. Chromium carbide microstructure

The wear resistance of wear plate depends mostly on the hardness, shape, size, amount and distribution of the chromium carbide hard particles.

As you can check on the picture, the carbide (Cr7C3) volume fraction on the microstructure is above 50%.

3. Bonding strength between the overlay and base plate.

The overlay and base plate are very well bonding. The overlay will penetrate into base plate about 0.8mm-1.8mm, reaching up to 350Mpa in our tests.

Customer Visits
Customer Visits

Comments and feedback:




Good quality and flatness is our first sight. After discussing on their booth, our team think we find a better producer with very good and competitive price and quality. One more important thing is their professional, skilled and young technican team.



The Wodon abrasion and impact wear plate samples consisted of a high chromium white iron deposit on a steel substrate. The hard facing microstructure contained typically a high volume percent of primary carbides.  The primary carbide sizes were typically less than 25μm in diameter, which was considered good for hard facings of these types.




La fabrica de Wodon nos ha impresionado por el rigor del control de calidad y la organizacion. Los productos tambien presentaron buena performance en nuestros testes y estamos satisfetchos con la parceria que estamos desarrollando.


FAQ

Q: Are you trading company or manufacturer ?

A: We are ISO certified flux cored welding wire and CCO wear plate factory.



Q: Are you able to produce customized chemical composition and dimension?

A: Yes, we could offer special welding wire and wear plate according customers' requirement.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-45 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 20~30% T/T in advance, balance against the copy of BOL. Other payment terms are negotiable.



Q: Do you provide after-sales service ?

A: Our company has a professional after-sales service team, with many years of experience not only on hardfacing products and applications, but also on the operation of application equipment. We are able to quickly solve customer's problems. If there are any quality problems, the responsible person will provide reasonable solutions within 12 hours after being notified.
